ATX
USB3.0*1+USB2.0*2+HD AUDIO
3.5" HDD: 2 2.5" SSD: 2
Left Side Panel: Tempered Glass
CPU Max H / GPU Max L: 175MM / 360MM
Model
B6
Structure Dimensions(L*W*H)
370*205*438MM
Product Dimensions(L*W*H)
385*205*465MM
Package Dimensions(L*W*H)
505*270*453MM
Structure Thickness
0.6MM
Materials
SPCC 0.6MM
FRONT PANEL：METAL PLATE+LIGHT GUIDE PLATE
LEFT SIDE PANEL: TEMPERED GLASS
Form Factor
M-ATX/ATX
5.25""Cd ROM:0
3.5""HDD:2
2.5""SSD:2
CPU MAX Height
175MM
VGA MAX Length
360MM
I/O Panel
USB3.0*1+USB2.0*2+HD AUDIO
PCI Card Slot
7
Fan Support
FRONT：3*120 MM
BOTTOM：2*120 /2*140 MM
REAR：1*120 MM
Liquid Cooling Support
N/A
Power Supply Support
BOTTOM MOUNT
Net Weight
5.23KG / 11.53lb
6.04KG / 13.31lb
